Calpeda T 76/A

The Calpeda T 76/A pump can be used for a wide range of tasks due to its ability to work with liquids of different chemical composition at low and high temperatures: water supply for industry, agriculture, construction and housing and communal services. The pump is used to increase pressure in water distribution networks, lifts water from wells for delivery to the end user. For example, T and TP series equipment can be used to increase pressure, provide air conditioning and circulation, and in installations aimed at ensuring fire safety. Due to their convenient dimensions, T and TR pumps are often used in various conveyor industries, automated lines of various processing industries. In a special version, these pumps can pump water with increased salinity, as well as increased temperature. The pump design is compact, meeting the modern requirements of the industrial water supply and engineering systems industry. The pump is highly reliable, the materials included are cast iron, brass, bronze, as well as chrome, chrome-nickel and chrome-nickel-molybdenum steel. These materials provide stable protection against corrosion and oxidation, which increases the service life. The power of the Calpeda T 76/A pump is 1.1 kW, and the voltage is 380 V. The pump is equipped with an energy-efficient motor, which is suitable for continuous operation and high loads. The pump provides a pressure of 26 to 70 m, and a capacity of 0.48 to 3.6 m³/h.

Scope of application

• Construction
• Industry
• Agriculture and irrigation
• Residential and office buildings
• Air conditioning, cooling, circulation and boiler feed systems

Operating limitations

• Continuous operation mode
• Liquid temperature from -10°C to +90°C
• Ambient temperature no more than 40°C
• Manometric suction height no more than 7 m
• Maximum permissible final pressure in the pump body: T series 12.5 bar, TP series 16 bar
