Calpeda 6SDX 28/30

The Calpeda 6SDX 28/30 pump is a submersible borehole pump that is versatile and can handle a wide range of tasks. It has gained recognition in a wide range of areas, both in professional water supply and in domestic facilities, due to its highly reliable design, compact format and ease of use. High-tech materials such as AISI 304 chromium-nickel stainless steel and AISI 304 chromium-nickel-molybdenum steel, which the pump consists of, protect equipment from corrosion, oxidation and mechanical damage. The Calpeda 6SDX 28/30 pump can pump clean and slightly contaminated liquids. It is especially suitable for operating wells with water that has increased salinity, increased hardness and significant total mineralization. Suitable for use in deep wells for production requiring a lot of process water, for pig farms, poultry farms and other agricultural facilities, drinking water supply, as well as water supply for fire-fighting systems of varying complexity. Special versions with other voltages and a frequency of 60 Hz, as well as for liquids with a higher temperature are possible. The engine is designed to work with an inverter. The pump is designed for continuous operation. The power of the Calpeda 6SDX 28/30 pump is 26 kW, and the voltage is 380 V. The pump provides a pressure of 148 to 330 m, the capacity is from 6 to 39 m³ / h. Class "F" insulation for 4 "motors, class "E" for 6 ", 8 "motors. Protection class IP 68.

Scope of application

• Construction
• Industrial and domestic sphere
• Agriculture and irrigation
• Water supply
• Fire extinguishing system

Operating limitations

• Continuous operation mode
• Liquid temperature no more than 30°C
• Maximum amount of sand in water: 50 g/m3
